JD-2 - Low Pressure Industrial Air Switches

JD-2 - Low Pressure Industrial Air Switches

  • $70.30
  • Save $26


JD-2 can be used for Differential, Pressure, and Vacuum applications.

The JD-2 has a sensitive diaphragm,
single pole double throw snap action electrical switch,
visible on-off indicator in an aluminum housing.
Springs are adjustable and have duel scales calibrated in mm or inches of water.

There are five range scales:
Blue: .07" to 1.7" W.C. 801111301
(2mm to 43 mm W.C.)

Grey: 0.1" to 4" W.C. 801111302
(3mm to 102mm W.C.)

Purple: 0.1" to 10" W.C. 801111310
(3mm to 250mm W.C.)

Red: 0.1" to 24" W.C. 801111303
(3mm to 600mm W.C)

Orange: 5" to 35" W.C. 801111315
(125 mm to 875mm W.C.)
Set Point Indication



  • Manufactured by Antunes Controls
  • ELECTRICAL RATINGS:
  • 10 amps at 125 VAC,
  • 5 amps at 250 VAC,
  • 1/8 HP at 125 VAC,
  • 1/4 HP at 250 VAC,
  • Pilot Duty 125 VA at 125/250 VAC.
  • SPECIFICATIONS: Differential, Vacuum Pressure
  • MAXIMUM OPERATING PRESSURE: 35" WATER COLUMN
  • MAXIMUM PRESSURE SURGE: 3 psi
  • MAXIMUM AMBIENT TEMPERATURE: +140 degrees F/+60 degrees C
  • MINIMUM AMBIENT TEMPERATURE: -20 degrees F/-93 degrees C



Technical Literature:
